GMI D5072S Intrinsically Safe Isolator SIL2 Temperature Signal Converter, Multifunction

GET A QUOTE – For business orders requiring a written quote or for volume pricing please request a quote.

The Multifunction Temperature Converter D5072S accepts a low level dc signal from millivolt, thermocouple or 2-3-4 wire/RTD or transmitting potentiometer sensor, located in Hazardous Area, and converts, with isolation, the signal to drive a Safe Area load, suitable for applications requiring SIL 2 level in safety related systems for high risk industries. Output signal can be direct or reverse. Modbus RTU RS-485 output is available on Bus connector.

Cold junction compensation can be programmed as Internal: provided by an internal temperature sensor; Fixed: to a user-customizable temperature value. Modules are provided with alarm function, which is available via photoMOS output.

Click here to get the PPC5092  which is required to easily program D5072 model via PC standard USB Port.



We are an authorized i.safe MOBILE distributor shipping to locations in North America

$481.00

Connect with Hazardous Area Expert

Questions
or Volume Pricing?

Connect with Hazardous Area Expert:
281-978-2040 | Chat with Us
Get Quote

Description

  • SIL 2
  • Input from Zone 0 (Zone 20) / Division 1
  • Installation in Zone 2 / Division 2
  • mV, TC, 2/3/4wire res./RTD or potentiometer input
  • Inversion/scaling/custom output
  • Selectable CJC: internal PT1000, external RTD or fixed
  • Fastest integration time: 50 ms
  • Burnout/internal/cjc/in sensor fault monitor
  • Alarm output with user-settable trip points
  • Modbus RTU RS-485 for monitor & configuration
  • Fully programmable operating parameters
  • High Accuracy, μP controlled A/D converter
  • Three port isolation, Input/Output/Supply
  • 250 Vrms or Vdc (Um) max. voltage allowed to the instruments associated with the barrier.
  • LED indication for power, signal status and line fault conditions
  • 18-30VDC power supply range
  • Operating temperature range up to: -40 to +70³C (-40 to +158³F)

Technical Data

Weight .29 lbs (130 g)
Dimensions Width 0.50 in x Depth 4.84 in x Height 4.72 in (Width 12.5 mm x Depth 123 mm x Height 120 mm)
Variations Two Channel Available: D5072D
Accessories Bus Connector JDFT049, Bus Mounting Kit OPT5096
Programmable USB serial line Kit PPC5092 + SWC5090

Approvals







UL and cUL-Underwriters Laboratory
ATEX
IECEx
SIL-TUV
