Description
- Android™ 10
- 4G (LTE)
- Bluetooth® 5.0
- 4.5 in Gorilla Glass® 3. Generation
- Quick charge with magnetic charging port
- Universal, lateral ISM interface
- PTT ready (third party application provided)
- Usable with gloves
- 2-year warranty
Additional information
| Weight | .72 lbs |
|---|---|
| Dimensions | 3.10 × .98 × 6.20 in |
Technical Data
| Type | IS530.2 |
|---|---|
| Operating System | Android™ 10 |
| Size | 3.10 x .98 x .6.20 in (155 x 80 x 25 mm) |
| Weight | .72 lbs (325 g) |
| PTT ready | optional (third party application provided) |
| LWP ready | optional (third party application provided) |
| Bluetooth® | 5.0 |
| Frequencies | GSM 850/900/1800/1900 MHz WCDMA UMTS B1/B2/B4/B5/B8 LTE-TDD B38/B39/B40/B41 LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12 mit MFBI B13/B14/B17/B20/B25/B26/B28A/B28B/B30/B66 TD-SCDMA B34/B39 |
| Wi-Fi® | 2.4 GHz + 5 GHz IEEE 802.11 a/b/g/n/ac/e/k/r/h with max. 8 connections hotspot |
| NFC | Near Field Communication |
| Display | 4.5″ (11.43 cm) Gorilla Glass® 3. generation, usable with gloves |
| Processor | Qualcomm Snapdragon SDM660 Octa-Core |
| Memory | 64 GB internal memory, 54 GB accessible, 4 GB RAM |
| Micro-SD | up to 128 GB |
| Camera | 2 cameras, 13 MP AF rear camera and 5 MP front camera |
| Battery | 3600 mAh battery (replaceable) |
| Operation range from | -20 °C to 60 °C |
| Security updates | Fully compliant with the requirements for Android Enterprise Recommended Rugged Devices. Quarterly security updates at least for five years from the launch. |
| Major upgrade | At least one major upgrade to Android 10 or higher. |
Resources
- Datasheet
- Safety Instructions and Quick Start
- ATEX Certificate of Conformity
- IECEx Certificate of Conformity
- CSA Certificate of Compliance
- PCEC Certificate of Conformity
- EU Declaration of Conformity
K-COMM Push to Talk Solutions offers a push to talk solution that is tested and approved to run on the IS530.1 and IS530.2 Smartphones. Monthly subscription sold separately.
Approvals
- ATEX zone 2/22
(approved for Europe)
II 3G Ex ic IIC T4 Gc IP64
II 3D Ex ic IIIC T135°C Dc IP64 - IECEx zone 2/22
(approved for International)
Ex ic IIC T4 Gc IP64
Ex ic IIIC T135°C Dc IP64 - NEC500
(approved for North America)
Class I Div 2, Groups A, B, C, D, T4
Class II Div 2, Groups F, G, T135°C
Class III Div 2 - PCEC
(approved for China)
Ex ic II C T4 Gc
Ex icD 22 T135°C
Included
- IS530.2 Smartphone
- Battery
- USB-C Cable
- USB Magnetic Charging Cable
- Charger
- Quick Start Manual and Safety Instructions
