Description
GET A QUOTE – For business orders requiring a written quote or for volume pricing please request a quote.
The new IS930.1 is an extremely rugged tablet for use in Zone 1/21 Class 1/2/3 Division 1 hazardous areas. The tablet is available with the Android™ 13 operating system. Designed to be extremely portable and rugged, it can withstand the harshest environments and is built around the latest technology providing an exceptionally high performing mobile computing device for use across the whole plant. Includes a 2-year warranty.
Technical Data
| Type | IS930.1 |
|---|---|
| Operating System | Android™ 13 |
| LWP ready | optional (application of another provider needed) |
| Size | 6.14 x .14 x 9.33 in (156 x 22 x 237 mm) |
| Weight | 1.92 lb (869 g) |
| Processor | Qualcomm Snapdragon SDM660 Octa-Core Kryo Gold-Quad cores 2.2GHz Kryo Silver-Quad cores 1.8GHz |
| Protection type | IP68 |
| Frequencies |
GSM: 850/900/1800/1900 MHz WCDMA: B1/2/4/5/8 LTE-FDD B1/2/3/4/5/7/8/12 with MFBI B13/14/17/20/25/26/28A/28B/29/30/66 LTE-TDD B38/B39/B40/B41 TD-SCDMA: B34/B39 |
| Wi-Fi® | IEEE 802.11a/ b/g/n/ac/e/k/r/h with max. 8 connections hotspot |
| Bluetooth® | 5 |
| NFC | Near Field Communication |
| Display | 8“ multi capacitive touchscreen with a resolution of 1200 x 1920 pixel RugDisplay Glass |
| Memory | 64 GB internal memory, 54 GB accessible |
| Micro-SD | up to 128 GB |
| 2 Cameras | 13 MP rear camera and 5 MP front camera |
| Location | GPS, A-GPS GLONASS, Beidou, Galileo |
| Sensors | proximity sensor, light sensor, magnetic sensor, G-sensor, gyroscope, temperature and humidity |
| Battery | 8400mAh battery |
| Security updates | Fully compliant with the requirements for Android Enterprise Recommended Rugged Devices. Quarterly security updates at least for five years from the launch. |
| Major upgrade | At least one major upgrade to Android 10 or higher. |
Resources
- Datasheet
- Operating Manual
- Quick Start Manual
- Safety Instructions
- FCC Statement
- IC Statement
- ATEX Examination Certificate
- IECEx Certificate of Conformity
- CSA Certificate of Compliance
- EAC Certificate of Conformity
- KCs Certificate of Conformity
- INMETRO Certificate of Conformity
- PCEC Certificate of Conformity
- JNIOSH Certificate of Conformity
- SANS Certificate of Conformity
- EU Declaration of Conformity
Approvals
- ATEX zone 1/21
(approved for Europe)
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135°C Db IP6X - IECEx zone 1/21
(approved for International)
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db IP6X - NEC500
(approved for North America)
Class I Division 1, Groups A, B, C, D, T4
Class II Division 1, Groups E, F, G, T135˚C
Class III Division 1 - EAC
(approved for Russia)
1 Ex ib IIC T4 Gb X
Ex ib IIIC T135°C Db X - KCs
(approved for Korea)
Ex ib IIC T4
Ex ib IIIC T135°C - INMETRO
(approved for Brazil)
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db IP6X - PCEC
(approved for China)
Ex ib IIC T4 Gb
Ex ibD 21 T135°C - JNIOSH
(approved for Japan)
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db IP6X - SANS
(approved for South Africa)
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db IP6X
Includes
- Tablet with integrated battery
- Hand Strap
- Power Adapter universal
- Earphone
- i.safe PROTECTOR 2.0
- i.safe PROTECTOR 3.0
- Display Protection Foil
- Safety Instructions
- Quick Start Manual
