Xplore XC6 Series DMSR Dual-Mode Sunlight-Readable Ultra Rugged Tablet PC

SKU IS-930.1-1 Category

GET A QUOTE – Not available for purchase online. Please click the link to request a quote or call 281-978-2040.

The XC6 updates the iX104 line of ultra-rugged tablets with comprehensive upgrades to performance, display, and features in the same ultra-rugged design. The rugged specs of the XC6 outstrips the competition and withstand the harshest conditions. The XC6 is third-party tested to MIL-STD-810G certifications with an IP67 (dust-proof and water-proof) rating, and features the highest drop rating (7’) on the market. It is built to protect your data under real world conditions in the toughest environments.

Questions
or Volume Pricing?

Connect with Hazardous Area Expert:
281-978-2040 | Chat with Us
Get Quote

Description

Run Windows® 7 and 8.1 Professional in Hazardous Classified Locations and Extreme Environments

  • The Most Rugged Windows® Tablet on the market is ideal for industrial and outdoor applications.
  • Industry’s Best Sunlight-Readable Dual-Mode Display has up to 1300 NIT brightness for virtually any use situation.
  • Multi-Touch Resistive Display works with gloved hands even when soaking wet.
  • Dynamic Dual-Mode Technology supports both finger and active pen inputs without user intervention.
  • Integrated Sealed Biometrics Touchpad provides for finger-swipe authentication.
  • Intel® Core™ i5 4300U 1.9GHz Processor provides advanced powerhouse performance (optional “lite” model also available)
  • Dual SSD Drives in User Accessible Carrier enables RAID 0,1 configuration.
  • Low Total Cost of Ownership & Long Life Cycle thru easy access to most modules, plus in-field repairs and upgrades.
  • Docks & Accessories provide solutions for mobile and temporary or intermittent fixed installations, plus high performance GPS.
  • Integrated AT&T 4G LTE for fast connectivity, plus BT 4.0, 802.11ac, 10/100/1000 gigabit Ethernet, optional GPS.
  • Hazloc approvals for the U.S., Canada, and European Community.

Technical Data

TypeIS930.1
Operating SystemAndroid™ 9
LWP readyoptional (application of another provider needed)
Size6.14 x .14 x 9.33 in (156 x 22 x 237 mm)
Weight1.92 lb (869 g)
ProcessorQualcomm Snapdragon SDM660
Octa-Core Kryo Gold-Quad cores 2.2GHz
Kryo Silver-Quad cores 1.8GHz
Protection typeIP68
FrequenciesGSM: 850/900/1800/1900 MHz
WCDMA: B1/2/4/5/8
LTE-FDD B1/2/3/4/5/7/8/12 with MFBI B13/14/17/20/25/26/28A/28B/29/30/66
LTE-TDD B38/B39/B40/B41
TD-SCDMA: B34/B39
Wi-Fi®IEEE 802.11a/ b/g/n/ac/e/k/r/h
with max. 8 connections hotspot
Bluetooth®5
NFCNear Field Communication
Display8“ multi capacitive touchscreen with a resolution of 1200 x 1920 pixel
RugDisplay Glass
Memory64 GB internal memory, 54 GB accessible
Micro-SDup to 128 GB
2 Cameras13 MP rear camera and
5 MP front camera
LocationGPS,
A-GPS
GLONASS,
Beidou,
Galileo
Sensorsproximity sensor,
light sensor,
magnetic sensor,
G-sensor,
gyroscope,
temperatur and humidity,
Battery8400mAh battery
Security updatesFully compliant with the requirements for Android Enterprise Recommended Rugged Devices. Quarterly security updates at least for five years from the launch.
Major upgradeAt least one major upgrade to Android 10 or higher.

Approvals

  • ATEX zone 1/21
    II 2G Ex ib IIC T4 Gb
    II 2D Ex ib IIIC T135°C Db IP6X
  • IECEx zone 1/21
    Ex ib IIC T4 Gb
    Ex ib IIIC T135°C Db IP6X
  • CSA
    (approved for North America)
    Class I Division 1, Groups A, B, C, D, T4
    Class II Division 1, Groups E, F, G, T135˚C
    Class III Division 1
  • INMETRO
    (approved for Brazil)
    Ex ib IIC T4 Gb
    Ex ib IIIC T135°C Db IP6X
  • KCs
    (approved for Korea)
    Ex ib IIC T4
    Ex ib IIIC T135°C
  • JNIOSH
    (approved for Japan)
    Ex ib IIC T4 Gb
    Ex ib IIIC T135°C Db IP6X
  • SANS
    (approved for South Africa)
    Ex ib IIC T4 Gb
    Ex ib IIIC T135°C Db IP6X



Resources



Included

  • IS930.1 Tablet with Integrated Battery
  • i.safe PROTECTOR 2.0 USB Cable
  • i.safe PROTECTOR 3.0 Magnetic Charging Cable Charger
  • Hand Strap
  • Display Protection Foil
  • Quick Start Manual and Safety Instructions
