Description
**END OF LIFE on the aegex10™ Intrinsically Safe Tablet – These tablets are being replaced by their next generation intrinsically safe tablet. CONTACT US FOR MORE INFORMATION ON NEXT GENERATION or call 281-978-2040 to speak with one of our experts.**
The aegex10™ Intrinsically Safe Tablet is the most advanced, efficient, lightweight and rugged Windows tablet that is purpose-built for Zone 1 / Division 1 hazardous areas. Simple to deploy, it is the basis for an Industrial Internet of Things platform for hazardous industries, allowing operations to easily begin their digital transformation to Industry 4.0.
Technical Data
| Type | aegex10™ Intrinsically Safe Tablet |
| Size | Dimensions: 10.75 x .66 x 7.28 in (273 x 16.8 x 185 mm) |
| Weight: 2.16 lbs (980 grams) | |
| Processor | Intel Quad-Core Atom Processor 2.3GHz |
| Protection Type | IP65 |
| Wi-Fi® | Wi-Fi 802.11 ac/802.11 a/b/g/n dual band (2.4GHz and 5GHz) |
| Bluetooth® | 4.0 Low Energy Technology |
| Display | Screen: 10.1" AHVA Full HD Plus |
| Capacitive Touch: Multi-touch (even works with gloves) | |
| Resolution: 1920 x 1200 | |
| Storage/RAM | 128GB, 4GB RAM |
| Software | Windows 10 Pro |
| Camera | 8.0 megapixel auto focus rear-facing camera with flash, HD video |
| 2.0 megapixel front-facing camera | |
| Front and rear microphones | |
| Stereo speakers | |
| Location | GPS/GLONASS (cold start <30s, warm start <5s) |
| Sensors | Ambient light sensor |
| Accelerometer | |
| Gyroscope | |
| E-Compass | |
| SAR proximity sensor |
Approvals
Il 2G Ex ib IIC T6 Gb, Tamb = -10°C…+50°C
Il 2D Ex ib IIIC T85°C Db IP6X, Tamb =-10°C…+50°C
I M2 Ex ib I Mb, Tamb = -10°C…+50°C
IECEx 60079-0 & -11:
Ex ib IIC T6 Gb, Tamb = -10°C…+50°C
Ex ib IIIC T85°C Db IP6X, Tamb = -10°C…+50°C
Ex ib I Mb, Tamb = -10°C…+50°C
UL913 5th edition:
C I, II, III Div 1 Gr A-G T4, Tamb = -10°C…+50°C
CI Z0 Gr IIC T4 IP65, Tamb= -10°C…+50°C
CAN/CSA-22.2 Part 157
Resources
Includes
- aegex10™ Tablet
- Wall Charger (US, UK and EU Plugs)
