Description
GET A QUOTE – For business orders requiring a written quote or for volume pricing please request a quote.
Always a step ahead! The smart and innovative Class 1 Division 2 smartphone with the most advanced technology: First Bluetooth® 5.0 industrial smartphone with multi-functional ISM interface, a huge internal memory 64 GB and the highest camera resolution of its class. Includes a 2-year warranty.
Unlocked Phone – please refer to the frequency specifications shown in the datasheet for local cellular carrier compatibility.



Technical Data
Operating System | Android™ 13 |
---|---|
Processor | Qualcomm® Snapdragon SDM660 Octa Core |
Memory | 4 GB RAM 64 GB internal memory microSD up to 128 GB |
Frequencies |
2G GSM: 850/900/1800/1900 MHz 3G WCDMA: B1/2/4/5/8 4G LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12 MFBI/B13/B14/B17/B20/B25/B26/B28A/B28B/B29/B30/B66 4G LTE-TDD: B38/B39/B40/B41 4G LTE-TD: B34/B39 |
Dimensions |
Size: 6.11 x 3.02 x 0.98 in (155.3 x 76.7 x 25 mm) Weight: 0.72 lbs (325.0 g) |
Display | 4.5" (11.43 cm) Corning® Gorilla® Glass V3, usable with gloves |
Battery | 3600 mAh, 3.8 V, replaceable |
Camera | 13 MP AF rear 5 MP FF front |
Connectivity |
Wi-Fi®: 2.4 GHz + 5.0 GHz (IEEE 802.11 a/b/g/n/ac/e/k/r/h with hotspot) Bluetooth®: 5.0 GPS: A-GPS, Glonass, Beidou, Galileo NFC: Near Field Communication |
Types of Protection |
IP68: Dust-/waterproof MIL-STD 810H: Military-grade durability Usable Temperature Range: -20°C to +60°C |
Resources
- Datasheet
- Operating Manual
- Quick Start Manual
- Safety Instructions
- ATEX Certificate of Conformity
- IECEx Certificate of Conformity
- CSA Certificate of Compliance
- PCEC Certificate of Conformity
- EU Declaration of Conformity
K-COMM Push to Talk Solutions offers a push to talk solution that is tested and approved to run on the IS530.1 and IS530.2 Smartphones. Monthly subscription sold separately.
Approvals




- ATEX zone 2/22
(approved for Europe)
II 3G Ex ic IIC T4 Gc IP64
II 3D Ex ic IIIC T135°C Dc IP64 - IECEx zone 2/22
(approved for International)
Ex ic IIC T4 Gc IP64
Ex ic IIIC T135°C Dc IP64 - NEC500
(approved for North America)
Class I Div 2, Groups A, B, C, D, T4
Class II Div 2, Groups F, G, T135°C
Class III Div 2 - PCEC (approved for China)
Ex ic II C T4 Gc
Ex icD 22 T135°C
Includes
- Smartphone
- Battery
- Power Adapter universal
- USB-C Cable
- Magnetic Charger Cable
- Screwdriver
- Display Protection Foil
- Display cleaning cloth
- Safety Instructions
- Quick Start Manual
