Description
GET A QUOTE – For business orders requiring a written quote or for volume pricing please request a quote.
**CERTIFIED FOR USE ON THE VERIZON NETWORK**
**AT&T NETWORK READY DEVICE**
The 5G smartphone with a clear 6-inch full HD display is equipped with a high-end chipset, supports a wide range of frequency bands and offers the highest image quality through the 48 MP main camera. The high-quality processor ensures fast data processing for the most demanding industrial applications such as predictive maintenance. The 16-pin ISM interface provides a secure connection for approved accessories. Includes a 2-year warranty.
Unlocked Phone – please refer to the frequency specifications shown in the datasheet for local cellular carrier compatibility.
Technical Data
| Operating system | Android™ 14 |
|---|---|
| Processor | Qualcomm® QCM6490 Octa Core |
| Memory | 8 GB RAM 128 GB internal memory microSD to 128 GB |
| Frequencies | 2G GSM 850/900/1800/1900 MHz 3G WCDMA B1/2/4/5/8 4G LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12 MFBI/B13/B14/B17/B20/B25/B26/B28/B29/B30/B66/B71 4G LTE-TDD: B38/B39/B40/B41/B42/B43/B48 5G NR: n1/n2/n3/n5/n7/n8/n12/n14/n20/n25/n28/n30/n38/n40/n41/n48/n66/n71/n77/n78/n79 |
| Dimensions | Size: 7.09 x 3.34 x .81 in Weight: .93 lbs |
| Display | 6.0" (15.24 cm) Corning® Gorilla® Glass V3 usable with gloves |
| Battery | 4400 mAh replaceable |
| Camera | 48 MP AF rear 5 MP FF front |
| Connectivity | Wi-Fi® 6: IEEE 802.11 a/b/g/n/ac/e/k/r/ax/v with hotspot Bluetooth® 5.2 GPS, A-GPS, Glonass, Beidou, Galileo Near Field Communication |
| Types of protection | IP68 dust-/waterproof MIL-STD 810H Usable from -20 °C to +55 °C |
Resources
Approvals
ATEX Approved (Europe) II
3G Ex ic IIC T4 Gc
II 3D Ex ic IIIC T135°C Dc
IECEx Approved (International)
Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc
NEC500 Approved (North America)
Class I Div. 2 Groups A, B, C, D, T4
Class II Div. 2 Groups F, G, T4
Class III Div. 2, T4
KCs Approved (South Korea)
Ex ic IIC T4
TIIS Approved (Japan)
Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc
PCEC Approved (China)
Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc
Includes
- IS540.2 Smartphone
- Safety Instructions
- Screwdriver
- Quick Start Manual
- Power Adapter Universal
- Display Protection Foil
- Display Cleaning Cloth
- Battery
