BEKA BA304G Intrinsically Safe Loop Powered Digital Indicator, Field Mounting

Roll over image to zoom in Click on image to zoom

BEKA BA304G Intrinsically Safe Loop Powered Digital Indicator, Field Mounting

BEKA

Variations: Standard

Variant

Price:

$607.00

Quantity:

Intrinsic safety certification
Large non multiplexed displays, models with:

4 digits: 34mm high
5 digits: 29mm high + bargraph

IP66 GRP or Stainless-Steel enclosures
-40°C to +70°C operation
Internal calibrator
Root extractor and linearizer
Tare function

Optional:

Backlight - may be loop or separately powered
Alarms
Scale and tag labelling for no additional charge
Engraved Stainless Steel legend plate

Display Readability (Backlight Optional)
	No backlight Display readable in daylight.
	Backlight, loop powered Display readable in poor lighting conditions.
	Backlight, separately powered Display contrast enhanced in all lighting conditions. Backlight color is orange on Model BA326C only.

Description
Technical Data
Approvals
Resources

Description

GET A QUOTE – For business orders requiring a written quote or for volume pricing please request a quote.

This fourth generation intrinsically safe 4/20mA loop powered indicator has high contrast 4-digit, 34mm high displays with a very wide viewing angle. Operating over an extended temperature range it contains many standard features previously only available as options. Extensive thermal and vibration testing provides maximum reliability.

No additional charge is made for factory calibration or for scale and tag marking, however the indicators can easily be recalibrated on-site.

Supported by a three-year guarantee.

We are an authorized BEKA distributor shipping to locations in the United States.

Technical Data

Mounting & Enclosures	Field 122 x 120mm
Display Format	4 digits, 34mm high
Ingress Protection	IP66

Approvals

Certification
International IECEx	Ex ia IIC T5 Ga -40°C ≤ Ta ≤ +70°C Ex ia IIIC T80°C Db IP66 -40°C ≤ Ta ≤ +70°C
Europe ATEX	Group II Category 1G Ex ia IIC T5 Ga -40°C ≤ Ta ≤ +70°C Group II Category 2D Ex ia IIIC T80°C Db IP66 -40°C ≤ Ta ≤ +70°C
UK UKEX	Group II Category 1G Ex ia IIC T5 Ga -40°C ≤ Ta ≤ +70°C Group II Category 2D Ex ia IIIC T80°C Db IP66 -40°C ≤ Ta ≤ +70°C
USA ETL & Canada cETL Intrinsic safety	Class I, Div 1, Gp A, B, C, D T5 (USA & Canada) Class I, Zone 0, AEx ia IIC T5 Ga (USA) -40°C ≤ Ta ≤ 70°C Class II, Div 1, Gp E, F, G. Class III, Div 1 (USA & Canada) Zone 20 AEx ia IIIC T80°C Da (USA) -40°C ≤ Ta ≤ 60°C Ex ia T5 Ga -40°C ≤ Ta ≤ 70°C (Canada) Ex ia IIIC Da -40°C ≤ Ta ≤ 60°C (Canada)
USA ETL & Canada cETL Nonincendive	Class I, Div 2, Gp A, B, C, D T5 Class II, Div 2, Gp F, G Class III, Div 2 -40°C ≤ Ta ≤ 70°C
China CCC Ex	Ex ia IIC T5 Ga -40°C ≤ Ta ≤ +70°C Ex ia IIIC T80°C Db IP66 -40°C ≤ Ta ≤ +70°C
India CCOE/PESO	Ex ia IIC T5 Ga -40°C ≤ Ta ≤ +70°C Ex ia IIIC T80°C Db IP66 -40°C ≤ Ta ≤ +70°C
